BGE04020 40 x 20mm Compact DC Blower

Features

  • UL/cUL 62368-1 Approved Axial DC Fan

  • Axial DC fan frame & impeller manufactured of PBT (UL94V-0)

  • 2-Ball Bearing Axial DC Fan -10ｰC~70ｰC Operating Temperature Range

  • Fluid Bearing Axial DC Fan -10ｰC~50ｰC Operating Temperature Range

Cofan DC blowers feature high airflow, high reliability, and low noise proven with test reports in every shipment.

Part No
Voltage
V Range
Rated Current
Bearing
CFM
dBA
in/H2O
m3/min
mm/H2O
RPM
BGE04020B05H
5
4.5~5.5
0.25
B
2.5
37
0.38
0.11
9.7
5500
BGE04020B05M
5
4.5~5.5
0.2
B
2.1
33
0.23
0.09
5.9
4500
BGE04020B12H
12
7.0~13.2
0.15
B
2.5
37
0.38
0.11
9.7
5500
BGE04020B12L
12
7.0~13.2
0.08
B
1.6
27
0.13
0.07
3.2
3500
BGE04020B12M
12
7.0~13.2
0.1
B
2.1
33
0.23
0.09
5.9
4500
BGE04020B12U
12
7.0~13.2
0.18
B
3
45
0.56
0.12
14.1
6500
BGE04020F05H
5
4.5~5.5
0.25
F
2.5
37
0.38
0.11
9.7
5500
BGE04020F05M
5
4.5~5.5
0.2
F
2.1
33
0.23
0.09
5.9
4500
BGE04020F12H
12
7.0~13.2
0.15
F
2.5
37
0.38
0.11
9.7
5500
BGE04020F12L
12
7.0~13.2
0.08
F
1.6
27
0.13
0.07
3.2
3500
BGE04020F12M
12
7.0~13.2
0.1
F
2.1
33
0.23
0.09
5.9
4500
BGE04020F12U
12
7.0~13.2
0.18
F
3
45
0.56
0.12
14.1
6500
